500VA Automated Slide Stainer Histology Equipment 55 Piece Slide Capacity

Function and Characteristics:

1. LCD screen with entirely Chinese/English, and intelligent programme control, easy-to-use operate.

2. Procedures and steps are limitless programmable and be capable of infinite storage.

3. Super humanized design, any parameters can be set according to the operator’s demand.

4. Current working state is clearly displayed.

5. Arbitrarily pause or stop the staining procedure.

6. Full range of protection function, even if the exception or error operation occurred, it will not

damage the equipment.

7. Drive with the international standard timing belt drive, with the advantages of high temperature resistance, corrosion resistance, high transmission accuracy, positioning accuracy, low noise, long service life etc..

8. Good sealed of reagent vessel lid, any odor will not go away, and install with the exhaust pipe, activated carbon adsorption function, double purification function.

9. Floating type automatic flushing Function.

Technical Parameters

1. Reagent Vessel Number: 14 Vessels.

2. Dithering/Stirring times: set default as 0-99 sec, and dithering /stirring time can be set arbitrarily.

3. Dripping Stay Time: 0-99sec can be arbitrarily adjusted.

4. Single Vessel processing time: 0-99min can be adjusted.

5. Temperature of dry vessel can be kept within ambient temperature to 99℃.

6. Volume of Each Vessel: 1200ml.

7. Voltage: AC220V±10%; Frequency:50Hz.

8. Rated Power:≤500VA.

9.Overall Dimension: L×W×H=1220mm×480mm×530mm.

histopathology laboratory equipment

pathology laboratory instruments

500VA Automated Slide Stainer Histology Equipment 55 Piece Slide Capacity Images
